Integra Neo (Surface)

15 W ( 1425 System Lumens )
In stock
SKU
LHEAARP6PL1W015
Special Price ₹ 1 558.00 (incl. of all taxes) MRP ₹ 2 233.00 30% Off
Be the first to review this product
Net Quantity : 1 N

Key Features

  • Environment Friendly : Environment-friendly as it does not contain Mercury
  • Long life & Photobiologically Safe LEDs : L70B50: 50000 hours
  • Operating Temperature : -10 °C to +45 °C
  • Operating Voltage Range : 140 V - 270 V

Integra Neo (Surface)

Special Price ₹ 1 558.00 (incl. of all taxes) MRP ₹ 2 233.00 30% Off
Out Of Stock
Make an Enquiry
main product photo
1 / 1

Housing & Finish

Pressure die-cast aluminium heat sink for effective thermal management, sturdiness and excellent corrosion resistant fitted in white finish polycarbonate housing.

Optics

PC diffuser in opal finish for glare-free uniform light distribution alongwith PC reflector in white finish to enhance the lumen output of the fixture (For detailed photometric data, please refer LM79 report & IES file).

Light Source

High efficiency long life SMD LED module is mounted on MCPCB with lumen efficacy of ≥140 lm/W to enhance the lumen output.

Electronic Driver

Powered by an integral electronic driver in PC housing (SMPS based constant current supply) with Output Short-Circuit Protection, Surge Voltage Protection and other safety tests as per IS15885 Part2/Sec13.

Mounting

Back polycarbonate mounting plate is fixed to the wall/ceiling by 2 holes of Ø3.5 mm provided in it at a center distance of 100 mm and then fixture is fit to the mounting plate by rotating in anti-clockwise direction.

  • Dimension
    Ø 200 mm x 68.5 mm
  • Class Declaration
    Class II
  • IK Rating
    IK03
  • IP Rating
    IP20
  • Colour of Fixture
    White
  • Colour Temperature
    4000 K
  • CRI
    ≥80
  • Mains Current
    0.07 A
  • Nominal Voltage
    240 V
  • Power Factor
    ≥0.95
  • System Lumens
    1425 lm
  • THD
    ≤10 %
  • Wattage (W)
    15 W
  • Weight
    0.500 kg
