Phase Selector 8 Way Double Door 63 A Horizontal DB
Double Door
In stock
SKU
DRDSMHDOZ08063
Special Price
₹ 8 393.00
(incl. of all taxes)
MRP
₹ 12 910.00
35% Off
Net Quantity : 1 N
Key Features
- Raised Neutral Link
- IP 42 Design
- IEC 61439-3, IS 13032 & IS 8623
- Copper Bus Bars
- Factory Fit Masking Sheet
Delivery Details
Buy In Bulk
Looking to make bulk purchases? Enquire Now
Total
Special Price
₹ 8 393.00
(incl. of all taxes)
MRP
₹ 12 910.00
35% Off
Technical Specifications
- Country Of OriginIndia
- TypePhase Selector Horizontal
- Ambient Temperature0 °C to 50 °C
- Enclosure MaterialPowder coated CRCA steel sheet 1.0 mm
- Standard ConformityIEC 61439-3, IS: 13032 & IS: 8623
- Phase Selector Rotary Switch 3 nos.40 A / 63 A
- Rated Voltage & Supply System415 V ac, 50 Hz, 3 Φ & Neutral
- Round Indicator Switch3 numbers, R, Y & B
- Rated Current of Bus Bar100 A
- Bus Bar Withstand Capacity5 kA for 100 ms
- Copper Bus BarTin Plated
- Brass Neutral LinkNickel Plated
- Brass Earth BarNickel Plated
- IP ProtectionIP 42
- Relative Humidity10 % to 100 %
- Din BarZinc Plated
- Mounting OptionSurface/Flush
- FinishRAL 9010 J White
